Louis Ledoux

We propose a hardware generator of GEMM accelerators. Our generator produces vendor-agnostic HDL describing highly customizable systolic arrays guided by accuracy and energy efficiency goals. The generated arrays have three main novel aspects. First, the accelerators handle a large variety of computer number formats using intermediate representations based on our Sign Scale Significand (S3) format. Second, the processing elements perform all intermediate dot-product arithmetic operations required by the GEMM kernel without any intermediate rounding, which makes it possible to deliver better energy efficiency than state-of-the-art approaches while offering more accuracy and reproducible results. Third, our accelerators feature the Half-Speed Sink Down (HSSD) mechanism, which maximizes the overlap of host-accelerator data transfers with GEMM computations.We evaluate our automatically generated designs in a cutting-edge setup composed of a POWER9 host, CAPI (Coherent Accelerator Processor Interface) link, and a Virtex Ultrascale Plus FPGA. Arrays can operate at the speed of the link and saturate it to reach a 13GB/s throughput. Our fine-grain customization approach allows to cover a wide range of accuracy versus efficiency scenarios and can reach 0.65GOps/s/W while producing 1024 accurate bits or 148.7GOps/s/W with 6 accurate bits. Our configurations achieve up to 1613GOps/s system performance and power efficiencies of up to 240GOps/s/W for the FPGA. This automatic generator is the first being able to produce such a variety of designs. We improve the single-precision energy efficiency of state-of-the-art FPGA GEMM accelerators by 1.86×.

We present a versatile open-source framework designed to facilitate efficient, numerically-tailored Matrix-Matrix Multiplications (MMMs). The framework offers two primary contributions: first, a fine-tuned, automated pipeline for arithmetic datapath generation, enabling highly customizable systolic MMM kernels; second, seamless integration of the generated kernels into user code, irrespective of the programming language employed, without necessitating modifications. We employ this framework within a cutting-edge platform, comprising a Power9 host, an OpenCAPI link, and a Xilinx Virtex UltraScale+ FPGA. The framework demonstrates a systematic enhancement in accuracy per energy cost across diverse High Performance Computing (HPC) workloads displaying a variety of numerical requirements, such as Artificial Intelligence (AI) inference and Sea Surface Height (SSH) computation. For AI inference, we consider a set of state-of-the-art neural network models, namely ResNetl8, ResNet34, ResNet50, DenseNet121, DenseNet161, DenseNet169, and VGG11, in conjunction with two datasets, two computer formats, and 27 distinct intermediate arithmetic datapaths. Our approach consistently reduces energy consumption across all cases, with a notable example being the reduction by factors of 3.3x for IEEE754-32 and 1.4x for Bfloat16 during ImageNet inference with ResNet50. This is accomplished while maintaining accuracies of 82.3% and 86%, comparable to those achieved with conventional Floating-Point Units (FPUs). In the context of SSH computation, our method achieves fully-reproducible results using double-precision words, surpassing the accuracy of conventional double- and quad-precision arithmetic in FPUs. Our approach enhances SSH computation accuracy by a minimum of 5× and 27× compared to IEEE754-64 and IEEE754-128, respectively, resulting in 5.6× and 15.1 × improvements in accuracy per power cost.
